Durable Sintering Furnace with Advanced Thermal Control System Ensuring and Consistent Sintering Results in Manufacturing

Name: Durable Sintering Furnace with Advanced Thermal Control System Ensuring and Consistent Sintering Results in Manufacturing
Brand: Jingtan
Price: 10 USD

Price : USD10,000-80,000/SET

Packaging Details : wooden case

warranty : 1 Year

Place of Origin : China

Marketing Type : Ordinary Product

Certification : CE

Maximum Use Temperature : 1600℃,2000℃,2400℃

Applicable Industries : Manufacturing Plant, Powder matellurgy industry

Supply Ability : 10pcs/month

weight (kg) : 2000

core components : PLC, Pump

Payment Terms : L/C/T/T

video outgoing-inspection : Provided

Delivery Time : 60 days

brand name : Jingtan

Brand Name : Jingtan

High Temperature Volume : 0.01m³,0.02m³,0.03m³,0.05m³,0.1m³,0.15m³, 0.2m³,0.3m³

machinery test report : Provided

Temperature Measurement accuracy : 0.2~0.75%

MOQ : 1 set

Condition : New

place of origin : Hunan, China

Warranty of core components : 1 Year

Showroom Location : United States, Germany, Peru

Contact Now

Specification

Application:

The intermediate frequency induction sintering furnace produced by our factory is an intermittent gas (vacuum) protection furnace.

vacuum/atmosphere sintering of cemented carbide, copper-tungsten alloy, tungsten, molybdenum, alnico-cobalt permanent magnet, SmCo5, Sm2Co17, Ndfeb, titanium alloy and other alloy materials.

Product Advantage:

1).Performance intelligent electric furnace,specially suitable for cemented carbide industry (process permits can also be applied to other industries)

2).Absorb the temperature measurement, temperature control technology, intelligence, new material technology and furnace design
technology at home and abroad.

3).A single set of power supply can be configured with multiple electric furnaces, which are heated by electricity and cooled by
electricity respectively for a single furnace to achieve continuous work.

Maximum Use Temperature	1600℃,2000℃,2400℃
High Temperature Volume	0.01m³,0.02m³,0.03m³,0.05m³,0.1m³,0.15m³, 0.2m³,0.3m³
Working atmosphere n furnace	Vacuum,hydrogen, nitrogen,inert gases,etc
Temperature Uniformity	≤±10℃
Temperature Measurement	Infrared optical temperature measurement,temperature measurement range 800~2400℃ or 0~2400℃
Temperature Measurement accuracy	0.2~0.75%
Temperature Control	Program control and manual control
Temperature Control accuracy	±1℃
Limit heating rate	200℃/min(Empty Furnace,depending on the volume of high temperature zone and furnace structure)

Features:

Ultra-high temperature furnace body within 2400℃ can fully meet the sintering of various materials. Using digital display intelligent temperature control system, automatic precision to complete the temperature measurement and temperature control process, the system can be heated according to the given temperature curve, and can store 20 pieces of a total of 400 different process heating curve.

Adopt internal circulation pure water cooling system, digital flow monitoring system;High performance medium frequency contactor is used for automatic conversion of furnace body.

Comprehensive PLC water, electricity, gas automatic control and protection system.

Product parameter:

Durable Sintering Furnace with Advanced Thermal Control System Ensuring and Consistent Sintering Results in Manufacturing

Features 1:

Features 2:

Adopt internal circulation pure water cooling system, digital flow monitoring system;High performance medium frequency contactor is used for automatic conversion of furnace body.
Comprehensive PLC water, electricity, gas automatic control and protection system.

Quality Durable Sintering Furnace with Advanced Thermal Control System Ensuring and Consistent Sintering Results in Manufacturing for sale

Durable Sintering Furnace with Advanced Thermal Control System Ensuring and Consistent Sintering Results in Manufacturing Images
